RATING CAPACITY: 9,000 BTU/h AIR FLOW RATE: 315 CFM
EVAPORATOR CONDENSER
ENT. TEMP. °F (°C) AMBIENT TEMP. °F (°C)
W.B. D.B. 75 85 95 105 115
(23.9) (29.4) (35.0) (40.6) (46.1)
TC 9,120 8,680 8,170 7,610 6,980
CI 0.56 0.61 0.66 0.75 0.83
72 (22.2) SHC 7,120 6,910 6,670 6,410 6,120
59 76 (24.4) SHC 8,140 7,930 7,690 7,430 6,980
(15.0) 80 (26.7) SHC 9,120 8,680 8,170 7,610 6,980
84 (28.9) SHC 9,120 8,680 8,170 7,610 6,980
88 (31.1) SHC 9,120 8,680 8,170 7,610 6,980
TC 9,460 9,040 8,590 8,070 7,520
CI 0.56 0.62 0.67 0.76 0.84
72 (22.2) SHC 5,900 5,720 5,520 5,300 5,070
63 76 (24.4) SHC 6,930 6,740 6,550 6,330 6,100
(17.2) 80 (26.7) SHC 8,000 7,810 7,620 7,400 7,170
84 (28.9) SHC 9,020 8,840 8,590 8,070 7,520
88 (31.1) SHC 9,460 9,040 8,590 8,070 7,520
TC 9,820 9,430 # 9,000 8,520 8,000
CI 0.57 0.62 0.68 0.77 0.85
72 (22.2) SHC 4,690 4,530 4,360 4,170 3,970
67 76 (24.4) SHC 5,710 5,560 5,380 5,200 5,000
(19.4) 80 (26.7) SHC 6,780 6,630 6,450 6,270 6,070
84 (28.9) SHC 7,810 7,650 7,480 7,290 7,090
88 (31.1) SHC 8,830 8,670 8,500 8,310 8,000
TC 10,340 9,980 9,590 9,170 8,700
CI 0.57 0.63 0.69 0.78 0.86
72 (22.2) SHC 3,470 3,340 3,200 3,050 2,880
71 76 (24.4) SHC 4,490 4,360 4,220 4,070 3,900
(21.7) 80 (26.7) SHC 5,560 5,430 5,290 5,140 4,970
84 (28.9) SHC 6,590 6,450 6,310 6,160 6,000
88 (31.1) SHC 7,610 7,480 7,340 7,190 7,020
TC 10,550 10,210 9,850 9,430 8,990
CI 0.58 0.64 0.7 0.79 0.88
75 76 (24.4) SHC 3,210 3,090 2,980 2,840 2,700
(23.9) 80 (26.7) SHC 4,280 4,160 4,050 3,910 3,770
84 (28.9) SHC 5,300 5,190 5,070 4,930 4,790
88 (31.1) SHC 6,320 6,210 6,090 5,960 5,820
TC : Total Cooling Capacity (BTU/h)
SHC: Sensible Heat Capacity (BTU/h)
CI : Compressor Input (kW)
Rating conditions are M.R.= 2.33 US pints/h
: Outdoor Ambient Temp. 95°F DB
: Indoor Unit Entering Air Temp. 80°F DB / 67°F WB
