The analyzer performs measurements and updates the plot continuously if the Run Mode in the
«Setup» menu is set to Continuous. The sweep can be stopped at any time by pressing the
Run/Hold [►||] button. If the Run Mode in the «Setup» menu is set to Single Shot, the sweep
automatically stops on completion. Press the Run/Hold [►||] button to start a new sweep.
The impedance measurement data and marker positions are preserved when changing to the
Scalar Chart mode and vice versa. For example, markers can be set at the zero reactance
points of the plot (where the plot crosses the X axis) in the Smith Chart mode and see them in
Cartesian format in the Scalar Chart mode.
