Appendix H: Scale Presets
The following tables show the default scale presets:
Normal Min Max Scale
Rs 10 1000 Log
Xs -500 500 Linear
Rp 10 1000 Log
Xp -500 500 Linear
|Zs| 10 1000 Log
<Zs -100 100 Linear
VSWR 1.00 25.00 Log
RL -40 0 Log
CL 0 20 Log
|Rho| 0 1.0 Linear
<Rho -190 190 Linear
%Rp 0 100 Linear
Q 0 20 Linear
Cs -10000 10000 Linear
Ls -100 100 Linear
Cp -10000 10000 Linear
Lp -100 100 Linear
High Min Max Scale
Rs 10 5000 Log
Xs -2500 2500 Linear
Rp 10 5000 Log
Xp -2500 2500 Linear
|Zs| 10 5000 Log
<Zs -100 100 Linear
VSWR 1.00 100.00 Log
RL -60 0 Log
CL 0 30 Log
|Rho| 0 1.0 Linear
<Rho -190 190 Linear
%Rp 0 100 Linear
Q 0 50 Linear
Cs -100000 100000 Linear
Ls -1000 1000 Linear
Cp -100000 100000 Linear
Lp -1000 1000 Linear
Low Min Max Scale
Rs 0 250 Linear
Xs -125 125 Linear
Rp 0 250 Linear
Xp -125 125 Linear
|Zs| 0 250 Linear
<Zs -100 100 Linear
VSWR 1.00 10.00 Log
RL -20 0 Log
CL 0 10 Log
|Rho| 0 1.0 Linear
<Rho -190 190 Linear
%Rp 0 100 Linear
Q 0 20 Linear
Cs -1000 1000 Linear
Ls -10 10 Linear
Cp -1000 1000 Linear
