Default scale presets can be modified by the user by supplying special text files stored on the
analyzer’s disk. The file names for each of the scales have to be the following:
• «Scale» «Normal»  “scal_def.txt”
• «Scale» «High»  “scal_hig.txt”
• «Scale» «Low»  “scal_low.txt”
• «Scale» «Auto»  “scal_aut.txt”
The files must contain an entry for each parameter with the following syntax:
min,max,log {Y,N}
Note that logarithmic scales do not accept negative ranges.
Example (file name “scal_def.txt”):
10,1000,Y #Rs
-500,500,N #Xs
10,1000,Y #Rp
-500,500,N #Xp
10,1000,Y #|Zs|
-100,100,N #<Zs
1.00,25.00,Y #VSWR
-40,0,N #RL
0,20,N #CL
0,1.0,N #|Rho|
-190,190,N #<Rho
0,100,N #%Rp
0,20,N #Q
-10000,10000,N #Cs
-100,100,N #Ls
-10000,10000,N #Cp
-100,100,N #Lp
