User’s Manual
Rev 1.2.6 October 3
rd
, 2015 - 72 - © Melchor Varela – EA4FRB 2011-2015
Abbreviation Parameter Description
<Rho Reflection
Coefficient Angle
(S11 Angle)
It is a measure of the phase angle of the ratio of the
amplitude of the reflected wave to the amplitude of the
incident wave.
=
RhoR
RhoI
aPh tan
%Ref Pwr Percentage of
Reflected Power
100%
2
×= RhoRPwr
Q Quality Factor It is defined as the ratio of the energy stored in a
component to the energy dissipated by the component.
X
Q =
Cs Series
Capacitance
Equivalent series capacitance at the measurement
frequency
Ls Series Inductance Equivalent series inductance at the measurement
frequency
Cp Parallel
Capacitance
Equivalent parallel capacitance at the measurement
frequency
Lp Parallel Inductance Equivalent parallel inductance at the measurement
frequency
