Model BP 221S-0CE BP 161P-0CE BP 121S-0CE BP 61S-0CE
Type BC BC 100 BC BC 100 BC BC 100 BC BC 100
Accuracy class kkkk
Weighing range structure SuperRange PolyRange SuperRange SuperRange
Maximum capacity Max* g 220 30/60/ 120 61
110/160
Scale interval d* mg 0.1 0.1/0.2/ 0.1 0.1
0.5/1.0
Verification scale inter val e* g 0.001 0.001 0.001 0.001
Minimum capacity Min* g 0.01 0.01 0.01 0.01
Tare range (by subtraction) g –220 –160 –120 – 61
Range of use according to
Directive No. 90/384/EEC* g 0.01–220 0.01–160 0.01–120 0.01– 61
Response time (average) s ≤2
Allowable ambient operating temperature °C +5 ...+40
Operating temperature range °C +15...+25
Pan size mm Ø 80
Weighing chamber height mm 225
Dimensions (WxDxH) mm 204 x297x332
Net weight, approx. kg 5.4
Selectable weight units g, mg
External calibration weight
(of at least accuracy class…) g 200 (E2) 100 (E2) 100 (E2) 50 (E2)
Power requirements V~ Via AC adapter: STNG 6, 230 VAC or 115 VAC,
–20% ... +15% (IP 20 protection)
Frequency Hz 48– 63
Power consumption (average) VA 16 maximum; 8 average
Hours of operation with fully charged
YRB 05 Z external battery pack, approx. h 32
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, odd;
transmission rates: 150...19,200 baud;
1or 2 stop bits; software/hardware handshake
Standard features/equipment supplied:
Analytical draft shield chamber x x x x
Dust cover x x x x
AC adapter; varies acc. to country x x x x
Built-in, motorized calibration weight x x x x
Level indicator x x x x
* = EC Directive No. 90/384/EEC for Non-Automatic Weighing Instruments applicable in the
EC/EU Member States
77
