Model BP 410 S-0CE BP 310 S-0CE BP 310 P-0CE
Type BA BC 200, BA BC 200,
BD BC 200 BD BC 200 BD BC 200
Accuracy class KKK
Weighing range structure SuperRange SuperRange PolyRange
Maximum capacity Max* g 410 310 60/120/310
Scale interval d* g 0.001 0.001 0.001/
0.002/0.005
Verification scale inter val e* g 0.01 0.01 0.01
Minimum capacity Min* g 0.02 0.02 0.02
Tare range (by subtraction) g –410 –310 –310
Range of use according to
Directive No. 90/384/EEC* g 0.02–410 0.02–310 0.02–310
Response time (average) s ≤1.5
Allowable ambient operating temperature °C 0 ...+40
Operating temperature range °C +10...+30
Pan size mm Ø 115
Dimensions (WxDxH) mm 204 x297x130
Net weight, approx. kg 3.1
Selectable weight units g, kg
Power requirements V~ Via AC adapter: STNG 6, 230 VAC or 115 VAC,
–20% ... +15% (IP 20 protection)
Frequency Hz 48– 63
Power consumption (average) VA 16 maximum; 8 average
Hours of operation with fully charged
YRB 05 Z external battery pack, approx. h 25
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, odd;
transmission rates: 150...19,200 baud;
1or 2 stop bits; software/hardware handshake
Standard features/equipment supplied:
Round glass draft shield x x x
AC adapter; varies acc. to country x x x
Built-in, motorized calibration weight x x x
Level indicator x x x
* = EC Directive No. 90/384/EEC for Non-Automatic Weighing Instruments applicable in the
EC/EU Member States
78
