Sartorius FB - Weighing-in-Percent Application: Preparation and Settings

39
Operating the Scale
Preparation
To calculate a value in percent, the
reference percentage must be
known. This value can be entered
into the weighing-in-percent program
in one of three ways:
– The last reference percentage
entered is loaded and displayed
when you turn on the scale.
Place the corresponding weight
on the scale and initialize the
weighing-in-percent program;
– With automatic initialization
switched on, the scale goes into
the “weighing-in-percent” mode
when you turn it on and loads the
last reference percentage entered
as well as the corresponding
reference weight;
– Enter the reference weight
using the numeric keys and store
it (W100% soft key).
● Turn on the scale:
Press e/[ON/OFF]
> All display segments light up
briefly
● Select the Weighing-in-Percent
application in the Setup menu:
Press M
● Select menu:
Press the menu soft key
(w/[TOGGLE])
● Set parameter 2 1 5:
See “Configuring the Scale”
● Exit the Setup menu:
Press M
Setting Parameters for the Weighing-
in-Percent Application
k Access the Setup menu:
Select Menu
● Set parameters for:
– Storage accuracy:
3 5 Count/pct. param.
– Decimal places displayed:
3 6 decimals f. calc.
– Automatic initialization:
3 10 auto-start app.
– Automatic output of parameters
to interface port:
7 1 Print app. param.
See “Configuring the Scale”
● Exit the Setup menu:
Press M
Additional Functions
In addition to functions for:
– alphanumeric input,
– taring
(not during alphanumeric input),
– printing,
you can also access the following
functions from this application:
– calibration
(not during alphanumeric input),
– setup,
– turning off the scale.
Calibration/Adjustment
● Press [ISOTEST]/[TEST]
> See “Calibration/Adjustment”
for further instructions
Setup (setting parameters)
● Press M
> See “Configuring the Scale” for
further instructions
Turning Off the Scale
● Press e/[ON/OFF]
> The scale shuts off
> The display goes blank
