Overview of the Scales
FB6CCE-H(0CE), FB2CCE-S(0CE), FB12CCE-S(0CE), FB6CCE-S(0CE), FB12CCE-I(0CE)
“-0CE” identifies the scale as verified for legal metrology in the EU
1
)
No. Designation Spare Part
Order No.
1 Display and control unit
2 Load plate 69 LP0007
3 Load plate shield
(depends on type of model) 69 LP0008
4 Leveling foot 69 B20005
5 Shock absorber 69 LP0010
6 Metrological ID label (only on scales
verified for legal metrology in the EU
1
)
7 Tare key
8 Function keys
9 Print key
10 Numeric keys
No. Designation Spare Part
Order No.
11 Shift key for entering letters
12 On/off key
13 Display
14 Lug for attaching an antitheft locking device
15 AC power socket
16 Data interface port
17 Level indicator
Not shown:
Dust cover for weighing platform 69 60FB01
Dust cover for display & control unit 69 60LP03
Caps and plugs for covering ports (set) 69 B20009
1
) including the Signatories of the Agreement on the
European Economic Area
* = As shown in this illustration, there are some differences between the standard and the U.S./Canadian keypad versions.
