Overview of the Scales
FBG34EDE-H, FBG34EDE-P, FBG16EDE-H, FBG12EDE-P, FBG64EDE-S, FBG64EDE-H
No. Designation Spare Part
Order No.
1 Level indicator
2 AC power socket
3 Data interface port
4 Tare key
5 Function keys
6 Print key
7 Numeric keys
8 Shift key for entering letters
No. Designation Spare Part
Order No.
9 On/off key
10 Display
11 Leveling foot 69 LC0093
12 Metrological ID label
(only on scales verified for legal
metrology in the EU
1
)
13 Load plate
14 Display and control unit
Not shown:
Dust cover for display & control unit 69 60LP03
1
) including the Signatories of the Agreement on the
European Economic Area
* = As shown in this illustration, there are some differences between the standard and the U.S./Canadian keypad versions.
1
2
3
11
12
14
13
