Satec PM130 User Manual

26
Trigger parameter Trigger Size, Unit
Limit/scale
c
Con-
ID byte Low High version
Low current L3 37125 2 A 0 Imax LIN3
High/low average values on any phase
High voltage
f
4864 2 V 0 Vmax LIN3
Low voltage
f
37376 2 V 0 Vmax LIN3
High current 4865 2 V 0 Vmax LIN3
Low current 37377 2 V 0 Vmax LIN3
High/low average total values (P)
High total kW import 5126 2 kW -Pmax Pmax LIN3
High total kW export 5127 2 kW -Pmax Pmax LIN3
High total kvar import 5128 2 kvar -Pmax Pmax LIN3
High total kvar export 5129 2 kvar -Pmax Pmax LIN3
High total kVA 5122 2 kVA 0 Pmax LIN3
Low total PF Lag 37892 2 0.001 0 1.000 LIN3
Low total PF Lead 37893 2 0.001 0 1.000 LIN3
High/low average auxiliary values
High neutral current 5377 2 A 0 Imax LIN3
High frequency
e
5378 2 0.01Hz 0 100.00 LIN3
Low frequency e 38146 2 0.01Hz 0 100.00 LIN3
High present demands
High volt demand L1/L12 (P)
f
5632 2 V 0 Vmax LIN3
High volt demand L2/L23 (P)
f
5633 2 V 0 Vmax LIN3
High volt demand L3/L31 (P)
f
5634 2 V 0 Vmax LIN3
High ampere demand L1 5635 2 A 0 Imax LIN3
High ampere demand L2 5636 2 A 0 Imax LIN3
High ampere demand L3 5637 2 A 0 Imax LIN3
High block kW demand (E) 5638 2 kW 0 Pmax LIN3
High block kVA demand (E) 5640 2 kVA 0 Pmax LIN3
High sliding window kW
demand (E)
5641 2 kW 0 Pmax LIN3
High sliding window kVA
demand (E)
5643 2 kVA 0 Pmax LIN3
High accumulated kW demand
(E)
5647 2 kW 0 Pmax LIN3
High accumulated kVA demand
(E)
5649 2 kVA 0 Pmax LIN3
High predicted kW demand (E) 5650 2 kW 0 Pmax LIN3
High predicted kVA demand (E) 5652 2 kVA 0 Pmax LIN3
c
For parameter limits, see Note
c
to Table 5-1
d
The setpoint is operated when the actual phase sequence does not match the indicated
phase rotation
e
The actual frequency range is 45.00 - 65.00 Hz
f
When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for any
other wiring mode, they will be line-to-line voltages.
(P) available in the PM130P and PM130E
(E) available in the PM130E
Table 5-19 Setpoint Actions
Action ID
No action 0
Operate relay 12288
Increment counter #1 16384
Increment counter #2 16385
Increment counter #3 16386

Satec PM130 Specifications

General

Frequency Measurement Range	45 to 65 Hz
Power Supply	85-265V AC/DC, 100-300V DC
Display	LCD
Communication	RS485
Digital Inputs	2
Digital Outputs	2
Protocols	Modbus RTU
Accuracy	0.2% of reading
Power Accuracy	0.5%
