1.7 Send Printer String

HOST REQUEST

Message type - '5'

Message Body - none

Message Body - Printer String

1.8 Examine Set Point Low Boundary

HOST REQUEST

Message Type - '6'

Message Body - the same as in the request '1' in section 6.6.3

Message Type - '6'

Message Body:

Sub field #1 Sub field #2 Sub field #3 Sub field #4

Sub field #1 - The same as in the HOST REQUEST

Sub field #2 - The same as in the HOST REQUEST

Sub field #3 - Set point delay in 'NNN.' format (length 4 bytes)

Will be '////' when the set point or low boundary is suppressed

Sub field #4 - Set point limit (length 1 to 7 bytes)

1.9 Change Set Point Low Boundary

HOST REQUEST

Message Type - '7'

Message Body:

Sub field #1 Sub field #2 Sub field #3 Sub field #4

Sub field #1 - The same as in the REQUEST TYPE '2'

Sub field #2 - The same as in the REQUEST TYPE '2'

Sub field #3 - Set point delay in 'NNN.' format (length 4 bytes).

To suppress this set point, this field should be filled with '////'

Sub field #4 - Set point limit (length 1 to 7 bytes)

Message type - '7'

Message Body - the same as in the HOST REQUEST

1.10 Reset Powermeter

Message Type - '8'

Message Body - none

REPLY - none
