Satec PM290 Reference Guide

5
1.3 Examine Set Point High Boundary
HOST REQUEST
Message Type - '1'
Message Body:
Sub field #1 Sub field #2
Sub field #1 - function of programming (length - 1 byte)
See Table 1-2 Sub field 1
Sub field #2 - setpoint serial number (length - 2 bytes)
See Table 1-2 Sub field 2
REPLY
Message Type - '1'
Message Body:
Sub field #1 Sub field #2 Sub field #3 Sub field #4
Sub field #1 - Same as for the HOST REQUEST
Sub field #2 - Same as for the HOST REQUEST
Sub field #3 - Set point delay in 'NN.N' format (length 4 bytes)
Will be '////' when the set point is suppressed
Sub field #4 - Set point limit (length 1 to 9 bytes)
Table 1-2 Setpoints
SETPOINT NAME Sub field #1 Sub field #2
(Setpoint #)
Sub field #4
(Limit)
Description
SETPOINTS FOR RELAYS 1 - 4
High Voltage 1...4 1 0 to V max N,NN...
NNNNNN
Low Voltage 1...4 2 0 to V max N,NN...
NNNNNN
High Current 1...4 3 0 to I max N,NN...
NNNNN
Max. Demand 1...4 4 0 to P max N,NN...
NNNNNN
Low PF. 1...4 5 0 to 1.00 N.NN
Unbalanced Current 1...4 6 0 to I max N,NN...
NNNNN
+kWH Pulsing 1 7 1 to 200 N,NN, NNN
High Reactive Power 1...4 8 0 to P max N,NN...NNNNN
NN
High Apparent Power 1...4 9 0 to P max N,NN...
NNNNNN
kVARH Pulsing 2 10 1 to 200 N,NN,
NNN
