Satec PM290 Reference Guide

6
SETPOINT NAME Sub field #1 Sub field #2
(Setpoint #)
Sub field #4
(Limit)
Description
kWH- Pulsing 4 18 1 to 200 N,NN,
NNN
SETPOINTS FOR CONFIGURATION
Wiring Configuration W 40 0. (3-OP)
1. (4L-n)
2. (3 dir)
3. (4L-L)
N
PT Ratio U 14 1.0 to 6500.0 N.N ... NNNN.N
CT Primary Current I 17 1 to 50,000 N ...
NNNNN
Max. Demand Period D 11 1,2,5,10,15,20,
30,60 or 255
for/ext. sync
N ... NNN
Ampere Max. Demand
Period
C 12 1 to 1800 N ... NNNN
Buffer Mode S 41 8 or 32 N or NN
Reset En/Disable R 42 0 (enable)
1 (disable)
N
Printer Period P 13 1,2,5,10,15,20,
30,60
N or NN
SETPOINTS FOR ANALOG OUTPUT
Voltage A A 21 136 '136'
Voltage B A 22 136 '136'
Voltage C A 23 136 '136'
Current A A 24 136 '136'
Current B A 25 136 '136'
Current C A 26 136 '136'
Apparent Power A 27 136 '136'
Power Factor A 28 136 '136'
React. Power A 29 136 '136'
Active Power A 30 136 '136'
Accumulated Power
Demand
A 31 136 '136'
Frequency A 34 136 '136'
SETPOINTS FOR ANALOG EXPANDER (OPTIONAL)
Voltage A E 21 0-14(CHAN.#) NN
Voltage B E 22 0-14(CHAN.#) NN
Voltage C E 23 0-14(CHAN.#) NN
Current A E 24 0-14(CHAN.#) NN
Current B E 25 0-14(CHAN.#) NN
Current C E 26 0-14(CHAN.#) NN
Apparent Power E 27 0-14(CHAN.#) NN
