Satec PM290 Reference Guide

16
Write Data to Powermeter (Function code 16)
Powermeter
Address
Function
(16)
Table
Number
Start
Address
Word
Count
Byte
Count
1 byte 1 byte 1 byte 1 byte 2 bytes 1 byte
Data Word 1 ... ... ... Data Word N Error Check
2 bytes ... ... ... 2 bytes 2 bytes
Meaning of message fields:
Table Number Powermeter internal data table number
Starting Address Address of the first word in the table to be read
Word Count Number of words to be written to the table
Byte Count Number of bytes to be written to the table
Response
Powermeter
Address
Function
(16)
Table
Number
Start
Address
Word
Count
Error Check
1 byte 1 byte 1 byte 1 byte 1 word 2 bytes
Note This request allows to write up to 125 words to the Powermeter.
Preset Single Register (Function code 06)
Powermeter
Address
Function
(06)
Table
Number
Start
Address
Data
value
HO
Data
value
LO
Error
check
1 byte 1 byte 1 byte 1 byte 1 byte 1 byte 2 bytes
Meaning of message fields:
Table number Powermeter internal data table number;
Starting Address Address of the first word in the table to be read
Data Value Data to be written to the table (HO - high order byte, LO - low order byte).
Response
The normal response to write request is retransmission of a write request.
