26 ACU-280 SATEL
ARD-200 - reorientation detector,
ATD-200 - temperature detector,
AVD-200 - shock detector and magnetic contact,
ATX-220 - hardwired zone expander: 2 x NC,
ATX-230 - hardwired zone expander: NC and roller shutter.
Sirens
ASP-200 - wireless outdoor siren.
ASP-215 - wireless indoor siren.
Hardwired zone / output expanders
ACX-210 - miniature hardwired zone / output expander.
ACX-220 - hardwired zone / output expander.
Controllers
ASW-200 - 230 VAC smart plug.
ASW-210 - flush-mounted wireless two-channel 230 VAC controller.
Other devices
APB -200 - wireless panic button.
ARF-200 - radio signal level tester.
ARU-200 - radio signal repeater.
ART-200 - wireless radiator thermostat.
6.2 Keypads
INT-KWRL2 – wireless keypad for the INTEGRA series control panels.
PRF-LCD-A2 – wireless keypad for the PERFECTA 64 M control panel.
VERSA-KWRL2 – wireless keypad for the VERSA series control panels.
6.3 Keyfob
APT-200 – bidirectional keyfob.
Keyfobs are discussed in a separate section (p. 66).
7 Installation of ABAX 2 wireless devices
After the controller has been installed, you can begin installation of the ABAX 2 wireless
devices. Before installing a device, check the level of radio signal received by the device from
controller and by the controller from device at the planned installation place. The ARF-200
tester is a useful tool to check the signal level. The level of signal received by
device / controller may not be lower than 40%. You can only install the device at the planned
location after making sure that the level of the radio signal is correct. If the radio signal level
at the planned installation place is too low, select another installation location. Sometimes it
is sufficient to move the device ten or twenty centimeters to obtain a significant improvement
of signal quality.
For detailed information about installation of individual devices, please refer to the manuals of
the respective products.
