70 ACU-280 SATEL
Serial number – serial number of the keyfob. Each keyfob has a unique serial number used
for user authentication.
Keyfob buttons – number of the function started on pressing the button. You can assign
a different function to each keyfob button. Right-click the field to select a function from the
list. The columns are labeled with the symbols corresponding to the keyfob buttons.
Event – if the symbol is displayed in the field, each use of the keyfob is saved to the event
log. If the field is empty, using the keyfob is not saved to the event log. Double-click the
field to make changes.
Keyfob LEDs – operating mode of the keyfob LED on pressing any button (the button does
not need to start any function):
* - LED is ON,
[empty field] – LED is OFF,
[number] – number of the output whose logic state is indicated by the LED (LED is ON –
output activated; LED is OFF – output deactivated).
You can select a different operating mode for each keyfob LED. Right-click the field to
select the LED operating mode from the list.
Buttons
Read – click to read the keyfob data from the controller.
Write – click to write the keyfob data to the controller.
– click to add the keyfob to the user.
– click to delete the user’s keyfob.
Adding a keyfob
1. Click the field in the “Serial number” column next to the name of the user to whom you
want to add the keyfob.
2. Click . The keyfob adding panel will be displayed.
3. Use the “auto” option to select the keyfob adding method:
– do not enable this option if you want to enter the keyfob serial number manually (this
method is recommended when other keyfobs are used in the area, which makes it
difficult to read the new keyfob’s serial number during transmission),
– enable this option if you want the keyfob serial number to be read during transmission
from the keyfob.
Entering serial number manually
1. Enter the keyfob serial number in the “Serial number” field.
2. Press any keyfob button.
3. When the “Device’s data read” message is displayed, click “OK”. The keyfob adding panel
will close.
4. Click the „Write” button to write the changes to the controller.
Reading serial number during transmission
1. Press any keyfob button.
2. When the serial number will be displayed, make sure it is the serial number of the added
keyfob, then press again any keyfob button.
3. When the “Device’s data read” message is displayed, click “OK”. The keyfob adding panel
will close.
