Satel CA-10 - Viewing troubles log; Current trouble check-out

CA-10 SATEL
13
2 - auxiliary alarm
keypad activated
3 - panic alarm
keypad activated
4 - anti-tampering keypad alarm
5 - three wrong access codes
alarm
9
- alarm activated in
partition 1
10
- alarm activated in
partition 2
11
- alarm activated in
partition 3
12
- alarm activated in
partition 4
Viewing troubles log [6]
The function allows the panel user to reproduce information about the system trouble
conditions from the panel memory log.
After calling the function in the LCD keypad, the message "View troubles log
ÇÈÅÆ
"
will be displayed. Pressing any of the arrow keys causes the date, time, and last trouble
type detected name to appear. On pressing
S
key the list of previously detected
troubles is displayed, on pressing
T
key the list of subsequent troubles.
After calling the function in the
LED keypad,
the ALARM and ARMED (PARTITION),
LEDs will go on, the TROUBLE LED will start blinking, and one of the LEDs 1 to 12 will
indicate the kind of trouble. The LEDs have the following meaning:
1
- output 1 trouble,
2
- output 2 trouble,
3
- output 3 trouble,
4
- 230VAC loss
5
- battery trouble
6
- keypad power supply trouble
7
- time not set
8
- printer trouble
9
- telephone line loss
10
- problem with transmission to monitoring station
11
- not used
12
- output 4 trouble
The previously detected troubles are displayed on repeatedly pressing any key. The [
*
]
key cancels the troubles log viewing function.
Current trouble check-out [7]
When the control panel signals a trouble detection (TROUBLE LED is blinking), you can
activate the current trouble check-out function by holding down the key [7].
In
the LCD keypad,
information on the trouble will be displayed When there are more
troubles, you can scroll through all the detected troubles list by pressing the keys
WS
or
TX
.
