USER MANUAL CA-10
4
Partially armed mode
The installer can determine the detectors in the system which will be excluded from the
supervision when the system is armed with a special access code (authority level 7).
The user can, by entering an appropriate code, arm the system in a chosen part of the
facility only.
Stay armed mode
In this mode the panel enables automatic bypassing of chosen detectors if after arming
the system the user did not leave the supervised area and did not violate the entry/exit
zone.
Operating Instructions
Operating of the alarm system consists basically in arming and disarming the system
and responding appropriately to the information the control panel may signal on the
keypad. The LED keypad conveys information on the status of the alarm system by
means of several LEDs and audible signals. The LCD keypad displays the information
about the status of the alarm system by means of a two-line, backlit LCD display (2x16
characters) and six additional LED controls.
There are three types of LED keypads (CA-10 KLED, CA 10 KLED-M, CA-10 KLED-S)
and three types of LCD keypads (CA-10 KLCD, CA-10 KLCD-S, CA-10 KLCD-L) that
can be used together with the CA-10 control panel. All of them fully support the alarm
system.
The CA-10 KLED keypads indicate simultaneously the status of one partition and up to
12 zones of the control panel, while the other ones can indicate the status of 4 partitions
and 16 zones. Figure 1 shows examples of LED and LCD keypads.
The keypad is provided with 12 keys, designated according to the telephone standard,
and intended for entering data. The additional 4 arrow keys in the LCD keypad allow the
user to move through the MENU and to select functions.
