CA-10 SATEL
7
Additional signaling, which is only provided in the CA-10 KLED-M and CA-10 KLED-S
keypads:
•
LED
designated with the symbol is lit when the keypad audible alarm (buzzer)
is on.
•
all LEDs blinking
simultaneously (with 0,5s/0,5s timing), along with audible
signaling, informs the user that connection between the keypad and the control
panel has been lost.
•
keypad illumination
blinking with a high frequency - the keypad is receiving data
from the control panel.
States of control panel armed zones in LCD keypad
The LCD keypad can indicate in the bottom line of its display, either periodically or
permanently, the state of control panel armed zones. Given below are symbols which
may be displayed at the successive items (1–16) and their meaning.

- zone free (not violated)
¦
- zone violated
S
- violated anti-tampering system of two-parameter zone
a
- there was alarm from a zone (alarm memory)
s
- there was tamper alarm from a two-parameter zone (tamper memory)
b
- zone bypassed
These symbols may be changed with the service function of LCD keypad.
States signaled with sound
The signals produced to confirm the operation on the keypad
•
three short
- system arming/disarming confirmation, deactivating type 13 (BI
switch) output,
•
two long
- wrong access code, canceling a function or incorrect data for
a function,
•
three long
- an attempt to arm the system when the zones with PRIORITY option
are violated (see Arming),
•
four short, one long
- correct user function completion, activating type 13 (BI
switch) output, or activating type 12 (MONO switch) output.
System events signaling
•
continuous signal
- alarm condition,
•
intermittent signal
- fire alarm,
•
one short signal every 3 seconds
– entry delay time (or service mode),
•
one long signal every 3 seconds
- exit delay time,
•
two short signals every 3 seconds
- trouble,
•
five short
- CHIME zone violated,
