LED Functions
ALARM
- alarm was triggered in the zone (when none of LEDs is blinking, the
alarm cause will be shown by the function "Viewing alarm log". The alarm
may have been caused by a zone not displayed in the partition, or the
zone belonged also to another partition, where alarm was cleared).
Note:
When the function „display service message after tamper alarm”
(FS131) is active, the ALARM LED, on detection of a tamper, is
blinking until the message is cleared with a service code
.
ARMED / PARTITION A B C D
(depending on the keypad type) – indicates the status
of a partition:
−
blinking of the LED
(with the ALARM LED off) signals the countdown
of exit delay time
−
steady light of the LED
signals the armed mode in the partition
The LEDs marked with letters A B C D correspond to numerical denotation
of partitions available in the system:
LED
A
– partition
1
LED
B
– partition
2
LED
C
– partition
3
LED
D
– partition
4
TROUBLE
- the LED is blinking when the control panel detects a technical problem,
a telephone messaging or reporting trouble. With the option „keypad
trouble alarm on until cleared” (FS131) active, it is blinking until the trouble
log is viewed (key 7 function) and the function is finished by pressing the
[#] key.
1-12
/
1-16
(depending on the LED keypad type) – the LEDs show the status of zones:
−
off - zone is free (not violated),
−
on - zone is violated,
−
on with extinguishing phase every two seconds - violated anti-tampering
circuit of 2EOL/NC or 2EOL/NO zone,
−
blinking quickly - zone caused an alarm condition,
−
flashing every two seconds - anti-tampering system caused an alarm,
−
blinking slow - zone bypassed.
Functions of the LEDs change on calling the service mode or entering the
user function mode.
Some states of the control panel are additionally indicated by combinations of lit LEDs
ALARM, ARMED (PARTITION), TROUBLE:
•
ALARM, ARMED (PARTITION) & TROUBLE blinking - control panel signals
entering the user function
•
ALARM blinking, ARMED (PARTITION) & TROUBLE on - control panel performs
function "Viewing alarm log"
•
TROUBLE blinking, ALARM & ARMED (PARTITION) on - control panel performs
function "Viewing trouble log"
