USER MANUAL CA-10
20
Time setting [CODE][
*
][6]
The function enables setting the panel’s clock.
In the
LED keypad
the programming procedure is as follows:
- HOURS, MINUTES - acceptance ([H][H][M][M][#]),
- DAY, MONTH - acceptance ([D][D][M][M][#]),
- YEAR - acceptance ([R][R][R][R][#]).
It is possible to quit the function already after programming either time or date by
pressing the [#] key twice.
In the
LCD keypad
the programmable parameters (time, data, year) can be edited with
additional keys:
◄
and
►
keys position the cursor,
▲
key deletes the character before
the cursor,
▼
key switches data entry mode (insert/typeover).
The function is only available to the master user and users with authority level 1.
MONO switch outputs activate [CODE][
*
][7]
The purpose of the function will be determined by the installer. It can activate e.g.
electric locks, bells, signal lamps, or any other devices.
After calling the function, the control panel generates two short beeps and waits for the
output number key (1-6) to be pressed. The control consists in activating the given
output for a period of time programmed in the control panel. Provision is made for
multiple control of the same output or control of different outputs of the MONO switch
type after single calling of the function. Correct performance of the control is confirmed
by four short and one long beeps, and refusal of the control - by two long beeps. The
control panel may refuse control, if the output is not of the SWITCH MONO type or if it
belongs to another partition. Pressing the key [#] or [
*
] will end the function. The control
panel will automatically end the function if none of the outputs is of the SWITCH MONO
type, or if no key on the keypad is depressed for 40 seconds.
The function is accessible to the master user, as well as to the users with authority
levels 1 and 5.
EXAMPLE: successive control of the outputs 4, 5, 4 (master code=1234)
[1234] [
*
] - calling the "user function" mode by the MASTER user
[7] - calling the function of "MONO switch outputs activate" (two short beeps)
[4] - monostable triggering of the output 4 confirmed by four short and one long
beeps
[5] - monostable triggering of the output 5 confirmed by four short and one long
beeps
[4] - monostable retriggering of the output 4 (four short and one long beeps)
[#] - end of the function (four short and one long beeps)
BI switch outputs activate [CODE][
*
][8]
The purpose of the function will be determined by the installer. It can be used e.g. for
switching on external lighting or any electrical equipment.
After calling the function, the control panel generates two short beeps and waits for the
output number key (1-6) to be pressed. The control consists in changing over the status
of the given output to its opposite, i.e. the inactive output gets activated and vice versa.
Provision is made for multiple control of the same output or control of different outputs
of the SWITCH BI type after single calling of the function. Activation of the output is
