26 VERSA SATEL
LED 8 - AUX supply output overloaded,
LED 9 - problem with telephone or Ethernet reporting to Station 1,
LED 10 - problem with telephone or Ethernet reporting to Station 2,
LED 11 - jamming ABAX system wireless devices / Ethernet module initialization error /
Ethernet network not available / no communication with device selected for
communication test (PING) / no connection to SATEL server / MAC/ID error,
LED 12 - short-circuit in communication bus,
LED 13 - control panel clock trouble,
LED 14 - control panel settings trouble,
LED 15 - violation of tamper zone (TMP zone on control panel main board or 6. 24H
TAMPER
type zone),
LED 16 - zone tamper,
LED 17 - too long zone violation,
LED 18 - no zone violation,
LED 19 - violation of 11. DETECTOR MASK or 19. TROUBLE type zones,
LED 20 - low battery in wireless device,
LED 21 - no communication with wireless device,
LED 22 - expander tamper,
LED 23 - no presence of expander,
LED 24 - loss of 230 V AC power in expander,
LED 25 - no battery / low battery in expander,
LED 26 - expander supply output overloaded,
LED 27 - low battery in user keyfob,
LED 28 - expander restart,
LED 29 - control panel restart,
LED 30 - trouble in control panel processor system (HSE).
3.17.2 Trouble handling procedure
Each trouble poses a danger to proper functioning of the alarm system and should be
repaired as soon as possible. If necessary, consult the installer.
In the event of failure of the control panel processor system (HSE), when you have
exited the 7. SYSTEM STATE function by using the key, the “Make VERSA panel
restart? 1=Yes” message will be displayed. Pressing the key will restart the
control panel and repair the trouble.
3.17.3 Trouble memory and clearing the trouble memory
The installer defines whether only the current troubles are to be presented, or also those
which have already ended. The keypad indicates the current troubles by steady-on LEDs,
and the troubles that have ended – by blinking LEDs.
You can clear the trouble memory after quitting the function:
1. Press to quit the function. The
LED will start blinking rapidly.
2. Press to clear the trouble memory (pressing another key will cancel clearing the
trouble memory).
If the SERVICE MESSAGE AFTER TAMPER ALARM option is enabled in the control panel,
only the installer can clear the tamper alarm memory.
