22 VERSA SATEL
LED OFF – the zone is to be unbypassed.
Press to quit the function. The zones will be inhibited/unbypassed.
3.11.2 Zone isolating
The isolated zone will remain bypassed until it is unbypassed by the user.
Enter the user menu and press in turn . The way of indicating the zone
status and the procedure are identical to those used for zone inhibiting.
3.12 Auto-arming deferment
Partition can be armed automatically by the timer on specific days at specific time. If the
installer defines the time by which the auto-arming is to be deferred, you can defer the
arming.
Enter the user menu and press in turn .
3.13 Setting the system time and date
Enter the user menu and press in turn . The currently programmed time
will be presented on LEDs (see page 11 Table 1):
hour – first digit on LEDs 1-4, second – on LEDs 5-8,
minutes – first digit on LEDs 9-12, second – on LEDs 16-19,
seconds – first digit on LEDs 20-23, second – on LEDs 24-27.
Enter successively the hour, mi
nutes and seconds, and then press . The date will be
presented on LEDs:
year – only two last digits: first on LEDs 1-4, second – on LEDs 5-8,
month – first digit on LEDs 9-12, second – on LEDs 16-19,
day – first digit on LEDs 20-23, second – on LEDs 24-27.
Enter successively the year, month and day, and then press .
3.14 Programming the timers
You can program 4 timers. The timers can control partition arming mode and outputs. The
timer compares the time with the control panel clock and executes the selected function at
the preset time.
The installer defines which outputs will be controlled by the timers.
1. Enter the user menu and press in turn . The programming is effected
by using the “step by step” method, hence the programming step number will be
presented on the
and LEDs of the first and second partitions (see: page 11, Table
1).
2. Step 1. Selecting timer to be program
med. Press in turn the suitable keys to select
a timer:
- timer 1,
- timer 2,
- timer 3,
- timer 4.
