SATEL VERSA 11
see Table 1. LEDs 1-4 present the first character, LEDs 5-8 – the second, LEDs 9-12 – the
third, LEDs 16-19 – the fourth, LEDs 20-23 – the fifth, and LEDs 24-27 – the sixth character.
LED status Digits and characters
0 – LED OFF
1 – LED ON
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Table 1. The way of presenting digits and characters in binary format on LEDs.
A
B
139
7 0 8
1 0
5
6
Fig. 2. Examples of presenting decimal values by means of LEDs. Example A: 931708.
Example B: 1605.
