SECTION 2: INSTALLATION
Page 2-6 GT Series Operator’s Manual
2.1.2 PARTS IDENTIFICATION
IDENTIFYING THE MAIN PRINTER PARTS
Lift this cover
upwards to access
ribbon and label
Pull down this panel
to access controls
Fixed front plate
Power switch
Pushing the I side turns the
printer ON. Pushing the O side
turns the printer OFF.
Operation Panel
Consists of an liquid crystal dis-
play screen, five status indica-
tors and the LINE and FEED
buttons.
Front Cover
(lifted up)
Ribbon take-up shaft
Head pressure
adjustment knob
Ribbon feeder
Label supply arm
Roll Guide lever
Roll Guide
Head lock lever
Head open lever
Front cover plate
Angled Front View
Front View
