SATO GT424 - Interface Card DIP SWITCH Settings (Wireless LAN)

Section 5: Interface Specifications
GT Series Operator’s Manual Page 5-3
5.3 INTERFACE CARD DIP SWITCH SETTINGS (LAN)
The GT400 series Local Area Network interface card (optional) contains DIP switches for
initializing LAN configuration, LAN printing configuration, and LAN card self-diagnosis. The DIP
switch functions are:
5.4 INTERFACE CARD DIP SWITCH SETTINGS (WIRELESS LAN)
The GT400 series Wireless Local Area Network interface card (optional) contains DIP switches
for initializing LAN configuration, LAN printing configuration, LAN card self-diagnosis and
wireless mode settings. The DIP switch settings must be made before installing the card into the
printer. The DIP switch functions are:
Switch No. GT400 series LAN Interface Card function
1Unused
2 Initializes LAN card configuration information
3 Prints LAN card configuration information (configura-
tion information such as the IP address will be printed)
4 Prints LAN card self-examination (results of LAN card
examination will be printed)
Switch No. GT400 series Wireless LAN Interface Card function
1Unused
2 Initializes LAN card configuration information
3 Prints LAN card configuration information (configuration information such as the
IP address will be printed)
4 Prints LAN card self-examination (results of LAN card examination will be
printed)
5 Wireless Communication mode OFF—OFF : 802.11 Ad hoc
OFF—ON : Infrastructure
ON—OFF : Ad hoc
ON—ON : Unused
6
