Using the Label Dispenser
This feature will print and dispense a single label. As soon as the label is removed the
printer will issue the next label. This procedure will set up the printer for dispenser
use.
2. Open the printer Top Cover.
Place two fingers at the top of the Dispenser
Cover and pull forward to release the cover.
3. Fit the label roll into the printer and remove
the first few labels from the backing paper.
Position the edges of the roll underneath the
two label guides.
Label
Guides
9
1. SWITCH TO THE DISPENSE MODE:
- Press the <F1> key.
- Select 2. Profile and press <Enter>.
- Select 1. Dispense and Press <Enter> to
return to the Format menu .
- The printer is now set to Label dispensing
Dispenser
Cover
To Next Page
