Installation Procedure
1. Locate the die marks on the service part rear rail.
2. Align a sliding square or similar tool to the line at
the tip of the arrow in the die mark and scribe a
line across the rail.
3. Use the same tool to transfer this scribed line
onto the sides and the weld flanges of the rail.
4. Place a mark forward, towards the rear of the
arrow, 25 mm (1 in) from the scribed line on all
3 sides of the service rail.
5. Use the tool to scribe a line on all 3 sides and
weld flanges of the rail.
6. Cut at the scribe line at the rear of the arrow.
876931
872758
872758
2003 Saturn Ion
3-153
2003 Saturn Ion
