Structure Identification (cont’d)
Number Description Procedure
8
Wheelhouse Replacement – Front
Wheelhouse Replacement - Front on
page 3-32
9
Wheelhouse Extension Replacement – Front
Wheelhouse Extension Replacement -
Front on page 3-34
10
Rail Replacement Front Compartment – Side Upper
Rail Replacement Front Compartment -
Side Upper on page 3-36
11
Rail Sectioning Front Compartment – Side Upper
Rail Sectioning Front Compartment -
Side Upper on page 3-39
12
Plenum Panel Replacement – Upper
Plenum Panel Replacement - Upper on
page 3-43
13
Plenum Panel Replacement – Lower
Plenum Panel Replacement - Lower on
page 3-45
14 Dash Panel Replacement Dash Panel Replacement on page 3-48
15
Cross Bar New Replacement – Floor Panel
Cross Bar No.1 Replacement - Floor
Panel on page 3-51
16
Rail Replacement Front Compartment – Front
Rail Replacement Front Compartment -
Front on page 3-53
17
Rail Replacement Front Compartment – Front Half
Rail Replacement Front Compartment -
Front Half on page 3-55
18
Rail Sectioning Front Compartment – Front
Rail Sectioning Front Compartment -
Front on page 3-59
19
Rail Replacement Front Side Underbody – Outer
Rail Replacement Front Side
Underbody - Outer on page 3-63
20
Suspension Support Replacement – Front
Suspension Support Replacement -
Front on page 3-66
21
Extension Replacement Front Compartment
Side Rail – Rear
Extension Replacement Front
Compartment Side Rail - Rear on
page 3-68
22
Windshield Frame Reinforcement Replacement –
Inner Upper
Windshield Frame Reinforcement
Replacement - Inner Upper on
page 3-70
23
Hinge Pillar Body Replacement – Front Inner
Hinge Pillar Body Replacement - Front
Inner on page 3-75
24
Hinge Pillar Body Reinforcement Replacement –
Front Inner
Hinge Pillar Body Reinforcement
Replacement - Front Inner on
page 3-73
25
Hinge Pillar Body Sectioning – Front
Hinge Pillar Body Sectioning - Front on
page 3-78
26
Roof Panel Replacement – Outer
Roof Panel Replacement - Outer on
page 3-81
27
Windshield Frame Header Panel Replacement – Front
Windshield Frame Header Panel
Replacement - Front on page 3-85
28
Rear Window Frame Header Panel Replacement – Rear
Rear Window Frame Header Panel
Replacement - Rear on page 3-87
29
Floor Panel Replacement – Center
Floor Panel Replacement - Center on
page 3-89
30
Rocker Panel Replacement – Inner
Rocker Panel Replacement - Inner on
page 3-93
31
Rocker Panel Extension Replacement – Inner
Rocker Panel Extension Replacement -
Inner on page 3-95
32
Rocker Panel Reinforcement Replacement – Inner
Rocker Panel Reinforcement
Replacement - Inner on page 3-97
33
Rocker Panel Reinforcement Sectioning – Inner
Rocker Panel Reinforcement Sectioning
- Inner on page 3-100
