Structure Identification (cont’d)
Number Description Procedure
34
Pillar Lock Front Door Sectioning – Outer
Pillar Lock Front Door Sectioning -
Outer on page 3-103
35
Pillar Lock Front Door Reinforcement Replacement
– Outer
Pillar Lock Front Door Reinforcement
Replacement - Outer on page 3-107
36
Pillar Lock Front Door Reinforcement
Pillar Lock Front Door Reinforcement
Sectioning - Outer on page 3-109
37
Pillar Lock Front Door Replacement – Inner
Pillar Lock Front Door Replacement -
Inner on page 3-112
38
Pillar Lock Front Door Sectioning Replacement – Outer
Pillar Lock Front Door Reinforcement
Sectioning - Outer on page 3-109
39
Rear Window Reinforcement Replacement – Lower Front
Rear Window Reinforcement
Replacement - Lower Front on
page 3-114
40
Rear Window Panel Replacement
Rear Window Panel Replacement on
page 3-116
41
Rear Window Reinforcement – Rear
Rear Window Reinforcement
Replacement - Rear on page 3-119
42
Pillar Lock Rear Door Replacement – Inner
Pillar Lock Rear Door Replacement -
Inner on page 3-121
43
Body Side Panel Replacement – Outer
Body Side Panel Replacement - Outer
on page 3-123
44
Rear Compartment Floor Panel Sectioning
Rear Compartment Floor Panel
Sectioning on page 3-126
45
Wheelhouse Replacement – Rear Inner
Wheelhouse Replacement - Rear Inner
on page 3-130
46
Quarter Panel Sectioning – Outer
Quarter Panel Sectioning - Outer on
page 3-133
47
Quarter Panel Replacement – Inner
Quarter Panel Replacement - Inner on
page 3-136
48
Cross Bar No. 4 Replacement – Floor Panel
Cross Bar No.4 Replacement - Floor
Panel on page 3-140
49
Cross Bar No. 4 Extension Replacement – Floor Panel
Cross Bar No.4 Extension Replacement
- Floor Panel on page 3-138
50
Cross Bar No. 5 Replacement – Floor Panel Center
Cross Bar No.5 Replacement - Floor
Panel on page 3-145
51
Cross Bar No. 5 Extension Replacement – Floor Panel
Cross Bar No.5 Extension Replacement
- Floor Panel on page 3-143
52
Rail Replacement Rear Side Underbody
Rail Replacement Rear Side
Underbody on page 3-147
53
Rail Sectioning Rear Side Underbody
Rail Sectioning Rear Side Underbody
on page 3-150
54
Rail Side Underbody Gusset Replacement – Rear
Rail Underbody Gusset Replacement -
Rear on page 3-155
55
Rail Side Underbody Reinforcement Replacement – Rear
Rail Underbody Reinforcement
Replacement - Rear on page 3-157
56
Impact Bar Anchor Plate Replacement – Rear Bumper
Impact Bar Anchor Plate Replacement -
Rear Bumper on page 3-160
57
Body Rear End Panel Replacement
Body Rear End Panel Replacement on
page 3-162
58
Battery Tray Replacement
Battery Tray Replacement on
page 3-28
