SBM IDRA - Immunity Test Results; Immunity Test: Electrostatic Discharge (ESD); Immunity Test: Radiated Electromagnetic

24
Test Points
Enclosure
Enclosure
Number of Discharges
10
10
Discharge Voltage (KV)
±15(air)
±8(contact)
Reference Standard
EN 60601-1-2
EN 60601-1-2
Immunity test
Tests done on both versions
Immunity for electrostatic discharge (ESD)
Reference document:
Level:
Test Equipment:
Conditions:
Uncertainty:
EN 61000-4-2
±15KV (air), ± 8KV (contact)
Schaner NSG 435 Environmental
Temperature: 20°C, RH: 40%
±5%
Radiated electromagnetic immunity
Reference document:
Test Level:
Test Equipment:
Environmental Conditions:
Uncertainty:
EN 61000-4-3
10V/m (modulated AM 80% 1kHz)
Generator: Rhode & Schwarz SM300; Amplifier: Kalmus 737FC;
Frankonia Amplifier FLG30C; Log- periodic antenna Frankonia BTA-M;
Management software Frankonia; Isotropic sensor PMM EP 330
Temperature 20°C, RH 40%
-2.56/+4.74 (dB)
Port
Enclosure
Enclosure
Frequency
Range (MHz)
30-1000
30-1000
Step Freq.
1% f
1% f
Polariz.
Antenna
Vertical
Horizontal
Test level
(V/m)
10
10
Reference
Standard
EN 60601-1-2
EN 60601-1-2
Measure distance: 3 meters
Worst case between the polarizations: V
Note:
1) Tablet version
2) PC version
