Scania DC16 - Hose Clamps

General tightening torques for screw joints
OPM 300 en-GB 111
© Scania CV AB 2020, Sweden
Hose clamps
Specifications in the tables show tightening
torque when tightening by hand.
A = width
(mm)
Tightening torque
Nm Lb-ft
7.5-9 1.5 1
12 5 4
A = width
(mm)
Tightening torque
Nm Lb-ft
20 10 7
25 20 15
327 162
D
A
The maximum tightening torque for a new unfitted
hose clamp is 1 Nm (0.7 lb-ft).
A
326 615
A
326 616
