Scania DI16 XPI series User Manual

Component identification
OPM 360 en-GB 14
© Scania CV AB 2017, Sweden
1.
Oil filler.
2. Air filter.
3. Sacrificial anodes (6).
4. Sea water pump.
5. Sea water intake.
6. Sea water outlet (1 on each side)
7. Valve for draining and filling coolant (1 on
each side behind the heat exchanger).
8. Oil plug.
9. Heat exchanger (1 on each side).
10. Fuel filter.
11. Hand pump for fuel.
12. Oil filter.
13. Expansion tank.
14. Level glass for checking coolant level.
15. Filling coolant.
16. Engine number, stamped into the cylinder
block.
17. Engine data plate.
18. Fuel manifold bleed nipple.
19. Bleed nipple on high pressure pump.
20. Charge air cooler.
21. Holes for draining condensation in charge air
cooler (2 off on the underside).
22. Oil dipstick.
23. Centrifugal oil cleaner.
Note:
The two water separating prefilters for the fuel
are located between the fuel tank and engine.
