Cooling system
OPM 360 en-GB 43
© Scania CV AB 2017, Sweden
Draining the sea water circuit
1. Close the bottom valve on the sea water inlet
and remove the connection pipe on the outlet
from heat exchanger (1).
2. Remove the cover from the sea water pump
to completely drain the pump (2).
The lowest point in the sea water circuit may be
at different points, but it is usually in the sea wa-
ter pump intake (3).
Plug the connections to prevent dirt ingress into
the engine.
Removing the charge air cooler
When the charge air cooler core needs cleaning,
the charge air cooler must be removed if there is
no space behind it to take out the core.
1. Make sure that the cooling system is com-
pletely drained as described in the previous
section.
2. Unscrew and remove the catwalk, protective
plate and the protective casing.
