12 ID-code programming

12.1 General description

12.2 Procedure

The unique ID-code required for radio communication is programmed between the

Portable Control Unit and Central Unit

TheCentralUnitmaystoretheID-codeofmaximumone(1)PortableControlUnit,ifanother

Portable Control Unit is required to operate the Central Unit via radio the ID-code procedure is

required to be done.

The previous ID-code will be overwritten.

1. Remove the battery pack from the Portable Control Unit. Test run the system/application via

cable control.

2. Leave the cable control connected between the Portable Control Unit and the Central Unit.

3. Press the Stop-button on the Portable Control Unit and deactivate the Central Unit via the R/M-

switch

4.ActivatetheCentralUnitinREMOTEmode,twistuptheStop-buttononthePortableControl

Unit.

5. Press and hold the On-button on the Portable Control Unit until you get a beep indication (ap-

prox 5 seconds). Release the On-button and wait; the Portable Control Unit will beep once followed

by the indication “Po-Id” in the LED-display (approx 8 seconds) then further followed by 5 beeps

and the deactivate.

6.WhenID-programmingiscompleted,removethecablecontrol,insertbatterypackandtest

run the system/application with radio control.

-Iftheinitialshortbeepisfollowedbyonelongbeep,theCentralUnitLED-displayindication“bL”

andPortableControlUnitthendeactivatestheID-programminghasbeenrejected,checkbelow

for further info.

Note:

Via cable control option you can easily determine via the LED-display if the ID-code is accepted; if

the LED-display indicates “2-” the ID-code programming procedure is required prior to radio opera-

tion,iftheLED-displayindicates“1-”;theID-codehasalreadybeenprogrammed/accepted.

Typical reasons to ID-programming failure:

The5thstep,pressingandholdningtheon-button,needstobeinitializedfrommax.10seconds

from activation of the Central Unit.

Thecablecontrolcableisdamaged,ensurethatnobatteryisinsertedinthePortableControlUnit

and that the system/application can be operated via cable alone.

ThePortableControlUnitdeactivatesimmediatelyuponstart-up,checkthatthePower-LED

remainslitduringtheprocedure,thePower-LEDshouldremainlituntilthelast5beepscanbe

heard; if the Portable Control Unit deactivates beforehand it has an internal malfunction.

Document type Document number PageRev

Service Manual S071 C

41 of 46
