Operating manual VISATRON® Oil Mist Detector VN2020 / VN2020 EX
Part number 183001 Version 3.0
3.3.2 Name plate for the complete VISATRON
®
VN2020 / VN2020 EX device
The name plate is attached to the outside of the connection box as shown in the figure
below.
Name plate, VISATRON
®
VN2020 connection box
1: Connection box
2: Name plate
The following information is provided on the name plate:
Name plate, VISATRON
®
VN2020 connection box
1: Manufacturer's details/company logo
3: Barcode with serial number (example)
Manufacturer's production period (example)
Manufacturer's part number (example)
2: Device type and designation
4: CE marking
The number under the barcode is identical to the serial number.
