Operating manual  VISATRON® Oil Mist Detector  VN2020 / VN2020 EX
Part number 183001  Version 3.0
79
ASSEMBLY AND INSTALLATION
Terminal box for VN2020: Insert wire break resistors (installation steps 1-3)
1: Connection board, VN2020 terminal box
2: Wire break resistors, VN2020 terminal box
6.4.2.2 Electrical installation of the VN2020 terminal box
 Section 6.4.2 Electrical installation of the terminal box VN2020 series
All the electrical terminal connections are on the connection board of the terminal box, to
which the free cable ends of the relay and alarm supply lines that are already prepared
and the power supply are connected.
WARNING
Failure to comply with the safety instructions may result in major damage to property
or the environment and in serious injury or death.
 Familiarise yourself with the basic safety instructions before starting electrical
installation.  Section 2.4 Basic safety instructions
2
3
Range of
resistors
