Schiller AT-1 - Test Equipment

Chapter 5
Adjustments
SCHXLLER AT-I 3-Channel ECG Unit
SERVICE HANDBOOK Issue 3 September 1999
Test Equipment
The following proprietary and dedicated test equipment is required to fault frnd and carry out all
board checks and adjustments on rhe AT-1.
The list of proprietary equipment is not comprehensive. Recommendations of suitable proprietary
test equipment can
be obtained from the SCHILLER Service Deparrment.
Proprietary Test EquipmenUToois
0 ECG Emulator, e.g. Phantom 320
0 Oscilloscope
0 DigitaiMultimeter
0 Standard tool kit with a seiection of cross-bladed, flat-bladed and posi-dtive screwdrivers,
pliers and general tools
0 ScHlLLER 10 lead patient cable Number 2.400070 (2. jooO71 for USA)
Page 5.4
