Schlage CO100 - Overview

3 • Schlage • CO-100 user guide
Overview
The Schlage CO-100 is a keypad-only off-line electronic lock in the CO-Series product line.
• This product is listed for UL294 and ULCS319.
• Two factory-congured functions are available: 1) Classroom/Storeroom, and 2) Ofce.
• The lock is powered by four (4) AA batteries. See Batteries on page 10 for more
information.
• Outside lever is normally locked.
• Inside lever always allows egress.
Outside
Schlage Button
Outside Lever
Keyway
Inside
Thumbturn
Battery
Compartment
Optional
Inside Push
Button
Inside Lever
Keypad
CO-100-CY
CO-100-MS
CO-100-MD
CO-100-993
