Service Manual L
99
Trim Assembly Parts
Escutcheon Thru-Bolt/Screws
(Two required per lock)
Standard Screw Packs
Tamper Resistant Torx Screw Packs
Part Number Specify Finish Description Door Thickness
L583-119
•
L Escutcheon Thru-Bolts/Screws
1³⁄₈''
L583-120
•
1³⁄₄''
L583-121
•
2''
L583-122
•
2¹⁄₄''
L583-123
•
2¹⁄₂''
K510-389
•
N Escutcheon Thru-Bolts/Screws 1³⁄₄''
K510-390
•
2''–2¹⁄₄''
L583-287
•
L Escutcheon Mounting Screws, L0170 single –
L583-133
•
N Escutcheon Mounting Screws, L0170 single –
Part Number Specify Finish Description Contents
C203-736
455 Lock Case Mounting Screws (2) C603-256, #12-24 WMS PFH
C203-736
•
Strike Screws (2) C603-256, #12-24 WMS PFH
K110-020
•
Armor Mounting Screws (2) K510-210, #8-32 x ¹⁄₄'' PFHMS
K110-947
•
Rose Trim Thumbturn Screws (2) K510-445, #4 x ¹⁄₂'' POH AB
L283-100
Trim Mountings Screws and Posts, 1³⁄₄'' doors (2) L583-066, #8-32 x ¹⁄₂'' PFH
(2) L583-212, ¹⁄₄ - 28 x 2 2¹⁄₈'' POHMS
L283-101
•
L Escutcheon Thru-Bolts/screws, 1³⁄₄'' doors (2) L583-120
Part Number Specify Finish Description Contents
L283-121
•
Rose Trim without Thumbturn (2) Armor screws, L583-370, #8-32 x ¹⁄₄'' (T-15)
(2) Strike screws, L583-371, #12-24 x ¹⁄₂'' (T-20)
L283-123 •
L Escutcheon Trim for 1³⁄₄'' Doors
(2) Armor screws, L583-370, #8-32 x ¹⁄₄'' (T-15)
(2) Strike screws, L583-371, #12-24 x ¹⁄₂'' (T-20)
(2) Esc. mtg. screws, L583-373, 1/4-28 x 2¹⁄₈'' (T-30)
L283-122 •
Rose Trim with Thumbturn
(2) Armor screws, L583-370, #8-32 x ¹⁄₄'' (T-15)
(2) Strike screws, L583-371, #12-24 x ¹⁄₂'' (T-20)
(2) Thumbturn screws, L583-372, #4 x 2¹⁄₂'' (T-8)
XL11-848 •
N Escutcheon Trim for 1³⁄₄'' doors
(2) Armor screws, L583-370, #8-32 x ¹⁄₄'' (T-15)
(2) Strike screws, L583-371, #12-24 x ¹⁄₂'' (T-20)
(2) Esc. mtg. screws, L583-373, 1/4-28 x 2¹⁄₈'' (T-30)
NOTE: Torx screw packs are furnished with appropriate T-xx installation tools.
Drivers to Operate Occupancy Indicator
(L496, L/LV9486 and L/LV9496 functions)
L583-245 Breakaway bars for all door ranges.
