Service Manual L
95
Decorative Trim
Decorative Levers
Decorative Roses
NOTE: See Schlage Commercial Price book for available finishes.
Asti Lever (AST) Merano Lever (MER) Accent Lever (ACC) St. Annes Lever (STA)
A B Avanti Rose (AVA) Merano Rose (MER)
2¹⁄₈" diameter 2⁹⁄₁₆" diameter 2⁵⁄₈" diameter 2⁵⁄₈" diameter
Inside Lever Assembly
(Bushing attached at factory)
Outside Lever Assembly
09-402 09-401
Furnished with spanner wrench. Furnished with retainer seating tool.
