Trim Assemblies Chart
P/N Description
L0170 L0172
L460 L462 L463 L464 L480 L496
L9010 L9040
LV9040
L9040/XL11-446**
LV9040/XL11-446**
L9044*
LV9044
L9050
LV9050
L9056
LV9056
L9060
LV9060
L9070
LV9070
L9071
LV9071
L9076
LV9076
L9077
LV9077
L9080
LV9080
L9080EL
LV9080EL
L9080EU
LV9080EU
L9080EL-RX
L9080EU-RX
L9082
LV9082
L9082EL
L9082EU
J Outside Escutcheon & Bushing x Knob/Lever Except 93 Lever:
09-636 L & N x blank
••
09-636/
XL11-446
L x thumbturn
†
••
09-637 L & N x
emergency
button
••
09-639 L & N x full face
cylinder
••••••••••••••••••••••••••
09-640 L x concealed
cylinder/ind.
09-641 L x full face
cylinder/ind.
Outside N escutcheon & Bushing x 93 Lever:
09-650 Blank
••
06-651 Emergency
Button
••••
09-652 Full face
cylinder
••••••••••••••••••••••••
K 1¹⁄₄'' Armor Front x Schlage Logo:
09-661 Blank
09-662 Latch
•••••••
09-663 Latch & aux. latch
•••••••••• ••••••••••••
09-664 Latch & deadbolt
09-665 Deadbolt
09-666 Latch, aux. latch
and deadbolt
09-713 Latch, aux. latch
less UL stamp
••••
09-717 L400-Series
deadbolt
••••••
L 09-905 Classroom Turn
& 1¹⁄₈” Blocking
Ring
•
M Full Face Cylinder with Compression Ring and Spring:
20-001 Straight cam
••
30-001 Clover leaf cam
•
2
•• • ••••••••
22
••
22
••••••••
22
••
30-002 Hotel (handed)
† Not sold separately as a part.
* Available with rose trim only.
** Not available with N escutcheon.
NOTE: Standard cylinder part numbers are shown for cylinder function locks. See pages 103–113 for other cylinder options.
