24
4. Accessories.
4.3 Push bar
The push bar is height adjustable and equip-
ped with an integrated antirotation lock. In
addition, it can be dismantled. In order to
adjust the height, please loosen the clamp (A)
and bring the push handle to the required
height. In order to remove the entire push bar,
please loosen the clamp (B). Please ensure on
insertion that the push bar is inserted up to its
limit into the push handle holder, and cannot
be rotated.
Use the push bar only to guide the therapy bicycle! The push bar is NOT suited for
repositioning the therapy bicycle or lifting or tilting!
4.4 Parking brake for accompanying escorts
The parking brake for accompanying per-
sons (can only be used in connection with
the push rod) secures the therapy bicycle
against unintentional rolling away. The fun-
ction of the lever is similar to a normal brake
lever. For this reason, the parking brake can
also be used as a normal brake. If however
the brake should be locked in parking position, the claw (D) must be pres-
sed into the ratchet with the brake lever (C) pulled. Loosen the locking
device by pulling the brake lever (C).
Always ensure that the brake and the brake pads work and that they have been
adjusted (see Point 3.2.1).
4.5 Steering for accompanying persons
Steering for accompanying person (by means of steering linkage, incl.
handlebar lock limiter) allows the accompanying person to help determine
the direction of travel of the therapy bicycle by shifting the front wheel
without interrupting the user`s pedaling movements.
A
B
D
C
