Schuchmann MOMO - 9. Technical data; 9.1 Dimensions

43
9. Technical data.
12“ 16“ 20“ 24“ 26“
A*
Pedal to top edge of saddle
30 - 38
cm
42 - 57.5
cm
50 - 64.5
cm
59 - 76.5
cm
71.5 - 87.5
cm
A**
Pedal to top edge of saddle
33 - 41
cm
45 - 60
cm
52 - 68
cm
61 - 84
cm
73 - 95
cm
B
Saddle support tube to front
tube
33 cm 39 cm 45 cm 53 cm 58 cm
C
Wheelbase 64 cm 76 cm 89 cm 104 cm 112 cm
D
Full length 99 cm 122 cm 148 cm 168 cm 178 cm
E
Access point height 16 cm 18 cm 20 cm 22 cm 23 cm
F
Full width 43 cm 52 cm 62 cm 71 cm 76 cm
Tare weight 10.5 kg 13 kg 15 kg 18 kg 20 kg
max. load 35 kg 50 kg 65 kg 100 kg 100 kg
* Dimensions with standard saddle post / ** Dimensions with T-saddle post
9.1 Dimensions
9.2 Tyre pressure
The minimum and maximum tyre pressure is
indicated on the casing (A).
9.3 Torque information
A
Pedal crank
40 Nm
Front wheel
20 Nm - 22 Nm
Heinzmann wheel hub motor
35 Nm
Rear wheels not powered
25 Nm - 30 Nm
