9. Technical data.

9.4 E-drive

Control

Operating voltage 36 V

Max. current depending on design & operation: 10 - 33 A

Motor

Type PRA 180-25

Motor nominal voltage 22.8 VAC

Output 250 W Pedelec (DIN EN 60034-1)

Speed during travel on the ﬂat

depending on design & wheel diameter

approx. 60-330 1/min

Torque 11.4 Nm

Impulse torque up to 60 Nm

Overtemperature protection Type KTY84-130

Overall motor diameter Ø 220 mm

Weight 4.5 kg

Protection class IP54

Consumption 0.5 – 1 kWh/100km

Battery

Type Lithium ion battery

Nominal voltage 36 V

Capacity 11 Ah, 400 Wh

Charging time approx. 5.5 h (at charge current 2 A)

Temperature ranges

Operation (-)10 - 45°C

Charging 10 - 35°C

Storage (-)10 - 45°C

system

Protection class 3
