Technical data
12
01.00 | ECG | Assembly and Operating Manual | en | 389769
3 Technical data
3.1 Name plate
The name plate is located on the side of the controller cover:
Name plate
Information Description
Id. No. SCHUNK ID no.
Type Model
Serial no. Serial no. of the ECG
Work no. Order no. of the production
Voltage Rated voltage (mains)
Frequency Rated frequency (mains)
Channels Number of output channels
Phases Phases (mains)
Current Rated current (mains)
Icc Rated short circuit current
Year Year of manufacture
Weight Weight
Do not remove the name plate. When consulting with SCHUNK,
always specify serial and ID numbers.
