SCHUNK ECG Series - Basic Data

Technical data
01.00 | ECG | Assembly and Operating Manual | en | 389769
13
3.2 Basic data
Designation ECG
-C -R -W -C -R -W
01 02
ECG with a constant holding
force
X X
ECG with a preselectable
holding force
X* X
ECG with a constant holding
force for welding applications
(fusion welding processes)
X X
Mechanical operating data
Dimensions LxWxH [mm] 215x
110x100
288x
110x100
650x
110x100
Weight [kg] 1 1 2 1 1 2
IP protection class 20
Ambient temperature [°C]
Min.
Max.
+5
+40
Air humidity [%]
Min.
Max.
5
15
Electrical operating data
Power supply [VAC] 400
Maximum current [A]** 32
Rated frequency [Hz] 50
Optional versions***
Power supply [VAC] 200 – 230 – 460
Rated frequency [Hz] 60
*Possible combinations ECG-R01/Clarify EGM with SCHUNK.
**Depending on combination ECG/EGM
***If necessary contact SCHUNK.
More technical data is included in the catalog data sheet.
Whichever is the latest version.
