Design and description
16
01.00 | ECG | Assembly and Operating Manual | en | 389769
4.3 ECG-W design
ECG-W interfaces
Interface Description
1 Power area – supply voltage
2 Power area – magnetic system
3 Power area – relay
4 Control unit
5 Actuation area – fuse protection
6 Actuation area – signal outputs status display
7 Actuation area – signal inputs actuation EGM
