Assembly and settings
30
01.00 | ECG | Assembly and Operating Manual | en | 389769
Item Designation Function
1 Button & LED
"Enable"
Enable buttons "Magnetization"(2) and
"Demagnetization"(3); do this by
holding down the button. The LED lights
up as soon as the selected operation is
complete.
2 Button & LED
"Magnetization"
Perform magnetization; to do this press
the button at the same time as the
"Enable"(1) button. The LED lights up
as soon as the magnetic gripper is
magnetized.
3 Button & LED
"Demagnetization"
Perform demagnetization; to do this
press the button at the same time as
the "Enable"(1) button. The LED lights
up as soon as the magnetic gripper is
demagnetized.
4 Buttons & LEDs
"Holding force
level"
(Only ECG-R.)
Use the arrow buttons to preselect the
holding force level. Depending on your
selection, up to 8 LEDs will light up.
■ LED "Enable" and LED "Demagnetization" light up.
■ Manual operating unit is connected to the product.
Ø Position the magnetic gripper on the workpiece.
Ø Press the "Enable" and "Magnetization" buttons at the same
time.
✓ The magnetization operation is performed.
✓ LED "Demagnetization" and LED "Enable" go out.
✓ LED "Magnetization" lights up.
Ø Move and set down the workpiece.
Ø Press the "Enable" and "Demagnetization" buttons at the same
time.
✓ The demagnetization operation is performed.
✓ LED "Magnetization" and LED "Enable" go out.
✓ LED "Demagnetization" lights up.
Ø Remove the workpiece from the magnetic gripper.
